Backward Curved Centrifugal Fans Packaged – Hartzell Air Movement – Series 03P

Starting at $3,600.00

“Rapid-Ship” Fans Ship in 5 Working Days!

and with a 5-Year Product Warranty


Read More About:

Industrial Fans & Blowers
Centrifugal Fans and Blowers

Ships in 5 days!

Description

Performance range: from 775 CFM to 20,350 CFM and static pressures 2 to 10″ w.g.

Features Include:

  • Clockwise rotation (CCW not available from stock) with top horizontal discharge standard. Rotatable in field. Stock fans cannot be rotated to BAD, TAD, and DB. (Flanges interfere with base.).
  • Class II construction. Housing of heavy gauge hot rolled steel.
  • Wheels are non-overloading backward curved, with single thickness airfoil blades.
  • Fans are stocked with shafts and bearings to accommodate maximum performance as shown.
  • Weather cover, drilled inlet and outlet flanges (1-1/2” wide), and ceramic shaft seal to minimize leakage standard.
  • Belt drive fan.
  • Maximum temperature is 250°F.

Options:

  • Steel drain kit
  • Inlet & outlet guards
